ITC T-120DTB

ITC T-120DTB

Parça Numarası: T-120DTB

$0.00

Ürün Açıklaması

DİJİTAL MİKSER AMPLİFİKATÖR

Ürün Bilgileri
  • Output: 4-16Ω, 100V
  • Output Power: 120W
  • Input Sensitivity & Impedance: MIC1, 2, 3, 4
  • Input:5mV/600Ω Unbalanced 6.3 connector
  • AUX1, 2 Input: 350mV/10KΩ Unbalanced RCA connector
  • EMC Input: 775mV/10KΩ Unbalanced 6.3 connector
  • Output Sensitivity & Soure Impedance: MIX
  • OUT:1000mV/470Ω Unbalanced RCA connector
  • Tone: Bass: ±10dB at 100Hz Treble: ±10dB at 10KHz
  • Frequency Response: 50~16KHz(+1dB,-3dB)
  • S/N Rate: MIC1, 2, 3: 66dB; AUX1, 2: 80dB
  • THD: Less than 0.5%(at 1KHz,1/3 Rated Power)
  • Mute Function: EMC>MIC1>MIC2, MIC3, AUX1, AUX2
  • Capacity: 5 Zones
  • Channel Crosstalk: ≥50dB
  • Heat Dissipation: The fan starts work when powered on.
  • Winds flank in and out from the back, can lead to strong cooling effect.
  • With infinitely variable speed.
  • Protection: Short circuit, overload and overheat
  • Power Supply: ~220-240V /50Hz
  • Power Consumption: 160W
  • Dimension: 484×260×44mm
  • Weight: 3.7Kg
Teknik Özellikleri İndir (PDF)
